A door closer seems simple. It closes the door. But the closer is one of the most specification-sensitive pieces of hardware on a commercial opening — it's affected by door size and weight, fire rating requirements, ADA opening force limits, exposure conditions, and the specific geometry of the opening it's mounted to. Get it right and it disappears into the background. Get it wrong and you'll be back adjusting, replacing, or defending it to an inspector.
This article covers how door closers work, how to size and specify them correctly, what ADA and fire code require, and when a full automatic operator is the better answer.
How a Door Closer Works
A door closer is a hydraulic mechanism that uses a spring to store energy as the door opens and releases that energy in a controlled way to close the door. The hydraulic fluid inside the closer controls the speed of that release through a series of valves — typically a sweep valve that controls the main closing speed, a latch valve that controls the final few degrees of closing to ensure positive latching, and a backcheck valve that limits how hard the door can be opened (preventing the door from slamming against the stop and damaging the closer arm, frame, or wall).
These valves are adjustable on most commercial closers within specified ranges — the "adjustment range" that allows field tuning to the specific conditions of the opening. Understanding this is important because a closer that's not adjusted to the opening is a closer that either won't latch reliably or will slam through the latch engagement zone and create noise and wear.
Closer Sizing
Door closer "size" refers to the spring power — a higher size number means a stronger spring and more closing force. The standard commercial range runs from Size 1 (lightest) through Size 6 (heaviest), with Size 3 being the ANSI minimum for most standard commercial doors and Sizes 4 and 5 common on exterior doors and large, heavy doors.
The size needed at any opening is driven by door width and weight, exposure to wind load (exterior doors), and the specific mounting position being used. A closer that's too small for the door won't reliably close and latch it — especially on exterior doors fighting wind pressure. A closer that's too large will close the door with excessive force, creating a safety hazard and potential ADA compliance issues.
Many commercial closers are available in "adjustable size" configurations — a single unit that can be set to cover a range (typically sizes 1–6 or 3–6) by adjusting the spring tension. These are efficient for distributors and contractors managing multiple opening conditions on the same project.
Mounting Positions
The geometry of where the closer mounts relative to the door and frame affects how much mechanical advantage the closer has — and therefore what size is needed and how the door operates.
Regular arm (standard) mount: The closer body mounts on the door face on the pull side (the push side of the door), with an arm connecting to a shoe on the frame face. This is the most common mounting and provides the most mechanical advantage, allowing a smaller or lower-size closer to do the work.
Top jamb mount: The closer body mounts on the frame face, with the arm extending to the door. Used when mounting on the door face isn't practical — storefront entries, doors with overhead obstructions, or aesthetic considerations. Requires a larger size closer for the same door than regular arm mount.
Parallel arm mount: Both the closer body and arm shoe mount on the door face (push side). Used at exterior openings where the closer needs to be on the inside (secure side) of the door but the door swings outward. The arm runs parallel to the door when open, hence the name.
The door prep, the frame, and the hardware schedule all need to reflect the mounting position being used. Specifying a closer without specifying the mounting position leaves the installer to improvise, which sometimes produces the wrong result.
ADA Opening Force Requirements
The Americans with Disabilities Act Accessibility Guidelines (ADAAG) set a maximum opening force for interior doors: 5 pounds of force to open a door on an accessible route. Exterior doors are not subject to a federal force limit under ADA, though many state and local codes have their own limits.
The practical implication: interior doors on accessible routes with closers must be adjusted so the door can be opened with no more than 5 lbf. This is a real constraint. A closer set to Size 4 or 5 on an interior door may not be adjustable down to ADA compliance at that size — and a door that doesn't comply on an accessible route is a liability and an accessibility failure, not just a code check mark.
Specifying a closer with delayed action (a feature that holds the door open momentarily to allow slower-moving users to pass through) and sizing it correctly for the application are the tools for balancing self-closing requirements with ADA force limits. When both are required at the same opening — fire door that must be self-closing and on an accessible route — the closer selection has to satisfy both requirements simultaneously.
Fire Door Closer Requirements
Fire-rated doors are required to be self-closing and self-latching under NFPA 80. The closer must be capable of reliably closing the door and engaging the latch from any open position — not just from a few degrees of opening, but from a fully open door.
This means fire door closers are generally sized up from what ADA considerations alone might suggest. The tension required to ensure reliable closing from 90+ degrees of opening is higher than what's needed just to close a door from 30 degrees. Fire door closers should be tested at full open position — if the door doesn't close and latch from fully open, the closer needs adjustment or replacement.
Hold-open closers (with a fusible link that releases the hold-open function at elevated temperatures) are a legitimate option for fire doors that need to be held open during normal operations. The hold-open function releases automatically when the link reaches its rated temperature, allowing the closer to close the door. These are code-compliant for fire doors where hold-open is operationally necessary.
Magnetic hold-open devices tied to the fire alarm system are another option — the door is held open by the magnet until the alarm releases it. These require a compatible closer and connection to the fire alarm system.
Closer Brands and Grade
Commercial closers from manufacturers like LCN, Norton, and Sargent carry ANSI/BHMA Grade 1 ratings, meaning they've been tested to a minimum cycle count (typically 2,000,000 cycles for Grade 1) and meet specific force and function requirements. For standard commercial work, Grade 1 closers are the correct specification. Grade 2 closers exist for lighter-duty applications; Grade 3 is residential.
Automatic Operators
An automatic door operator powers the door open (and usually controls the close) using an electromechanical drive — eliminating the need for the user to apply force to open the door. Automatic operators are the right answer in several situations:
ADA accessibility requirements where force compliance can't be reliably maintained with a standard closer. High-use exterior doors, doors serving mobility-impaired populations, or doors where the combination of closer requirements and traffic makes consistent 5 lbf compliance impractical.
High-traffic entries where hands-free access is operationally valuable. Hospital main entries, grocery store receiving areas, building main entries on busy facilities — locations where the volume and type of traffic make an automatic operator a practical improvement.
Applications where the occupant population requires it. Senior living facilities, healthcare facilities, schools serving students with mobility needs — automatic operators in these environments aren't optional, they're the baseline.
Automatic operators require a more significant door prep and rough-in than a standard closer — electrical supply, activator placement (push plates, motion sensors, floor mats), and the operator hardware itself all need to be coordinated before the opening is finished. This is a coordination item that needs to be on the drawing and the hardware schedule early, not added in the field.
Low-energy automatic operators (sometimes called "power-assist" operators) are a middle ground — they require activation (a push-plate button, typically) and move the door more slowly than a full-power operator. They're appropriate for many accessibility applications and cost less than full-power systems.
Sizing a closer correctly, understanding the ADA constraints, and knowing when to step up to an automatic operator are the decisions that determine whether an opening works for everyone who uses the building — not just the average user. It's one of those specification decisions where getting it right matters every single day.
Next in this series: access control and electrified hardware — how electronics integrate into the physical opening.
